Specifiche

• Input signals Flow meter pulses 2.5 kHz TTL max. Media temperature Single Wire Bus
• Output signal (linearised & viscosity corrected) Flow rate (custom scaled) 0 to 10 V
• Flow rate metrological properties
• Accuracy +/- 0.1 %
• Response time 1 ms
• Low flow cut off 0.6 to 5 s
• Adjustable filtering 0 to 5 s
• Custom fluid characteristics Up to 10 fluid curves, 29 points each(RFID-Tag selectable)
• Supply voltage 9 to 32 V DC reverse polarity protected
• Power consumption ≤ 60 mA
• Degree of protection IP 67
• Operating temperature range −40 °C to +125 °C
• Electrical connections LEMO/Yamaichi size 0
• EMC EN 55011 EN 61000-4-2 bis EN 61000-4-6
• TEDS IEEE 1451.4:2004
• Calibration certificate included flow rate, analog output
• Housing material Anodised aluminium
• Weight 150 g, app.
• Accessories Mating connector for Flow and analog output, RFID Tag
• optional Accessories see separat data sheet
